sūsa Remote Oil Filter Stand - 92mm
P/N: 18-RFHU92-13-22
Original Price
$188.50
Current Price
$160.23
- INSTRUCTIONS -
The sūsa remote oil filter stand provides relocation of the oil filter for more convenient access of the filter and/or the easy installation of an oil cooler.
Machined from billet aluminum and finished with durable anodizing in titanium gunmetal gray.
Design provides multiple options for oil flow entrance & exit depending on application requirements. Included heavy-gauge steel mounting plate offers multiple orientations for adaptability.
The 92mm filter mount is designed for large-format spin-on oil filter canisters.
Notes:
- This item does not work with AN16 or banjo adapter fittings.
- Fitting Port Thread: Female ProLine (M22 x 1.5)
Includes:
- (x1) - sūsa Remote Oil Filter Stand - 77mm
- (x1) - 92mm Filter Landing Adapter w/ Buna X-Profile o-ring (SAE: 400-236)
- (x1) - Mounting Bracket
- (x4) - Screws - M6x14
- (x1) - Oil Filter Stem (select size)
- (x1) - M22x1.5 ProLine Plug
- (x1) - M22x1.5 to 1/8" NPT ProLine Port Bushing
- (x1) - 1/8" NPT Plug
- (x1) - sūsa Thread Glue - Red
Specifications
| Filter landing / sealing surface | Port Size | Filter nipple thread | Part Number | |
|---|---|---|---|---|
| ID | OD | |||
| 70 mm (2.76 in) |
92 mm (3.62 in) |
M22x1.5 | 13/16"-16 | 18-RFHU92-13-22 |
| M20x1.5 | 18-RFHU92-20-22 | |||
| M22x1.5 | 18-RFHU92-22-22 | |||
| 3/4"-16 | 18-RFHU92-34-22 | |||
